Technical specifications

Dangerous goodsDG0

UN numbern/a

Weight1.5 lb

EU legislation2006/42/EC

Sound standardISO15744

Max working pressure7.0 bar

Max working pressure100 psig

Sound uncertainty3 dB(A)

Vibration value<2.5 m/s²

Weight0.7 kg

Model typeAngle

Sound pressure75 dB(A)

EC standardISO 11148-6

Air consumption at free speed13 cfm

Air consumption at free speed6 l/s

Max working pressure100 psi

Recommended hose size6 mm

Shut-offYes

Vibration standardISO28927-2

Air inlet thread1/8 in

Free speed430 r/min

Angle head centre to side11 mm

Angle head height28.5 mm

Length287 mm

Torque range max9 Nm

Torque range min1.3 Nm

Ford certificationCA N3/4/5 TR

EAC certifiedYes

Torque range min0.96 ft lb

Torque range max6.64 ft lb

UK legislationS.I. 2008/1597

UK standardISO 11148-6

SCIP512325c7-97f9-4ab7-9ad4-7c27c003eb75

LTV009 R09-42

8431 0278 15
