Technical specifications

Material contains a batteryYes

Sound standardISO15744

Model typeAngle

Vibration value< 2.5 m/s²

Vibration standardISO28927-2

Motor voltage typed.c.

Torque range max7 Nm

Torque range min1.4 Nm

Torque range min1.0 ft lb

Torque range max5.2 ft lb

Shut-off systemTransducer

KC certifiedYes

Sound pressure< 70 dB(A)

CCC certifiedNo

ETL control number3008099

ETL listedYes

Type of battery1 Li-ion

Weight incl. bat.3.55 lb

Weight of battery7 g

Motor power500 W

CS distance9.5 mm

EAC certifiedYes

Weight1.24 kg

WEEE5 - Small equipment <50cm

ETL text6 - 62841-2-2

BatteryLi-Io 14/18 V

Height88.6 mm

Length289.6 mm

Width74.6 mm

Motor voltage35 V

CMIIT ID2020AJ14906

FCC IDXF6-M7DB7

IC ID8407A-M7DB7

KC IDR-R-50A-IXB Series

Weight incl. bat.1.61 kg

Weight2.73 lb

Speed range max1205 r/min

EU legislation(EU) 2022/30, 2006/42/EC (MD), 2011/65/EU (RoHS), 2014/53/EU (RED), 2015/863/EU (RoHS amendment)

EC standardEN 18031-1:2024, EN 300 328 V2.2.2, EN 300 440 V2.1.1, EN 301 489-1 V2.2.3, EN 301 489-17 V3.1.1, EN 301 893 V2.1.1, EN 50566:2017, EN 61000-6-2:2019, EN 61000-6-3:2007+A1:2011, EN 61000-6-4:2007+A1:2011, EN 62209-2:2010+AC:2019, EN 62841-1:2015+AC:2015+A11:2022, EN 62841-2-2:2014+AC:2015

Tolerance ClassTK15

Capability classFK-MFU25

Output typeHexagon, Female

EU SAR value0.55 W/kg

Output size1/4"

UK legislationS.I. 2008/1597, S.I. 2012/3032, S.I. 2017/1206

SCIP2ee62b66-a918-4ad7-a599-0d8f252a030c

Output featureBit holder

Tool familyICB

Torque scatter 3s≤ 5 %

UK standardEN 300 328 V2.2.2, EN 300 440 V2.1.1, EN 301 489-1 V2.2.3, EN 301 489-17 V3.1.1, EN 301 893 V2.1.1, EN 50566:2017, EN 61000-6-2:2019, EN 61000-6-3:2007+A1:2011, EN 61000-6-4:2007+A1:2011, EN 62209-2:2010+AC:2019, EN 62841-1:2015+AC:2015+A11:2022, EN 62841-2-2:2014+AC:2015

ICB-A21-07-I06-HMI

8436 0026 08
