Technical specifications

Material contains a batteryYes

Sound standardISO15744

Model typeAngle

Weight1.6 kg

Weight3.5 lb

Vibration value< 2.5 m/s²

Vibration standardISO28927-2

Motor voltage typed.c.

Torque range max12 Nm

Torque range min3 Nm

Torque range min2.2 ft lb

Torque range max8.8 ft lb

CS distance11 mm

Shut-off systemTransducer

KC certifiedYes

Sound pressure< 70 dB(A)

ETL control number3008099

ETL listedYes

Weight incl. bat.2.1 kg

Weight incl. bat.4.6 lb

Type of battery1 Li-ion

Motor power1080 W

Weight of battery7 g

EAC certifiedYes

Width74.5 mm

WEEE5 - Small equipment <50cm

ETL text6 - 62841-2-2

Motor voltage35 V

BatteryLi-Io 14/18/36 V

Length419.6 mm

Height89.5 mm

CMIIT ID2020AJ15158

FCC IDXF6-M7DB7

IC ID8407A-M7DB7

KC IDR-R-50A-IXB Series

EU legislation2006/42/EC (MD), 2011/65/EU (RoHS), 2014/53/EU (RED), 2015/863/EU (RoHS amendment)

Speed range max1270 r/min

EC standard, , EN 300 328 v.2.2.2, EN 301 489-1 v.2.1.1, EN 301 489-17 v.3.1.1, EN 301 893 v.2.1.1, EN 55014-1:2017, EN 55014-2:2015, EN 61000-6-2:2019, EN 61000-6-3:2007+A1, EN 61000-6-4:2007+A1, EN 62841-1:2015, EN 62841-2-2:2014/AC:2015

Capability classFK-MFU25

Tolerance ClassTK10

Output typeHexagon, Female

EU SAR value0.55 W/kg

Output size1/4"

UK legislationS.I. 2008/1597, S.I. 2012/3032, S.I. 2017/1206

SCIPd9974dff-6c04-473b-9f99-7864a9eed89d

UK standard, , EN 300 328 v.2.2.2, EN 301 489-1 v.2.1.1, EN 301 489-17 v.3.1.1, EN 301 893 v.2.1.1, EN 55014-1:2017, EN 55014-2:2015, EN 61000-6-2:2019, EN 61000-6-3:2007+A1, EN 61000-6-4:2007+A1, EN 62841-1:2015, EN 62841-2-2:2014/AC:2015

Tool familyITB

Output featureBit holder

Torque scatter 3s≤ 3.5 %

ITB-A31-10-I06-HMI-H

8436 0035 11
