Technical specifications

Length223 mm

Material contains a batteryYes

Sound standardISO15744

Model typePistol

Vibration value<2,5 m/s²

Sound pressure<70 dB(A)

Vibration standardISO28927-2

Motor voltage typed.c.

Torque range min6 Nm

Torque range max25 Nm

Torque range min4.4 ft lb

Shut-off systemTransducer

CCC certifiedNo

KC certifiedNo

ETL control number3008099

ETL listedYes

Type of battery1 Li-ion

Height240 mm

Torque range max18.4 ft lb

IC ID5325A-0965

Weight of battery7 g

FCC IDPVH 0965

Width74 mm

Motor power500 W

EAC certifiedYes

BatteryLi-Io 18/36 V

CMIIT ID2018AJ0238

Motor voltage38.1 V

Weight incl. bat.1.83 kg

Weight incl. bat.4.034 lb

Weight1.33 kg

Weight2.932 lb

WEEE5 - Small equipment <50cm

ETL text6 - 62841-2-2

Speed range max1500 r/min

EU legislation(EU) 2022/30, 2006/42/EC (MD), 2011/65/EU (RoHS), 2014/53/EU (RED), 2015/863/EU (RoHS amendment)

EC standardEN 18031-1:2024, EN 300 328 V2.2.2, EN 300 440 V2.1.1, EN 301 893 V2.1.1, EN 301489-1 V2.1.1, EN 301489-17 V3.1.1, EN 50566:2017, EN 55014-1:2017, EN 55014-2:2015, EN 61000-6-1:2007, EN 61000-6-2:2005, EN 61000-6-3:2007+A1, EN 61000-6-4:2007+A1, EN 62841-1:2015, EN 62841-2-2:2015+AC1

Output typeHexagon, Female

Sound uncertainty pulse3 dB(A)

Vibration uncertainty pulse1,5 m/s²

Vibration value pulse12 m/s²

Sound pressure pulse80 dB(A)

Output size1/4"

UK legislationS.I. 2008/1597, S.I. 2012/3032, S.I. 2017/1206

UK standardEN 300 328 V2.2.2, EN 300 440 V2.1.1, EN 301 893 V2.1.1, EN 301489-1 V2.1.1, EN 301489-17 V3.1.1, EN 50566:2017, EN 55014-1:2017, EN 55014-2:2015, EN 61000-6-1:2007, EN 61000-6-2:2005, EN 61000-6-3:2007+A1, EN 61000-6-4:2007+A1, EN 62841-1:2015, EN 62841-2-2:2015+AC1

SCIP68c2f2d6-c770-45dc-b4e1-5cfc88785683

EU SAR value0.49 W/kg

Output featureBit holder

Tool familySRB

ETP SRB31-25-I06-BD

8433 3260 33
