技术规格

Sound standardISO15744

Vibration value<2.5 m/s²

Model typeAngle

Sound pressure<70 dB(A)

Vibration standardISO28927-2

Torque range max40 Nm

Torque range max29 ft lb

Torque range min9 ft lb

Torque range min12 Nm

Shut-off systemTransducer

KC certifiedYes

Weight4.7 lb

Material contains a batteryNo

Type of batteryn/a

BatteryLi-Io 30 V

Length507.8 mm

Motor power1500 W

ETL control number3008099

ETL listedYes

Motor voltage30 V

Weight2.15 kg

FCC IDPVH0965

IC ID5325A-0965

EAC certifiedYes

Weight incl. bat.3.29 kg

Weight incl. bat.7.3 lb

Height66 mm

CMIIT ID2016AJ1533

WEEE4 - Large equipment >50cm

Communication typeBluetooth/WLAN

ETL text6 - 62841-2-2

KC IDR-R-50A-STB3464

EC standardEN 300 328 V2.2.2, EN 300 440 V2.1.1, EN 301 489-1 V2.1.1, EN 301 489-17 V3.1.1, EN 301 893 V2.1.1, EN 50 566:2017, EN 55014-1:2017, EN 55014-2:2015, EN 61000-6-2:2019, EN 61000-6-4:2007+A1:2011, EN 62841-1:2015, EN 62841-2-2:2014 + AC:2015

EU directives2006/42/EC (MD), 2011/65/EU (RoHS), 2014/53/EU (RED), 2015/863/EU (RoHS amendment)

Speed range max450 r/min

Output typeSquare, Male

Output size3/8"

UK legislationS.I. 2008/1597, S.I. 2012/3032, S.I. 2017/1206

UK standardEN 300 328 V2.2.2, EN 300 440 V2.1.1, EN 301 489-1 V2.1.1, EN 301 489-17 V3.1.1, EN 301 893 V2.1.1, EN 50 566:2017, EN 55014-1:2017, EN 55014-2:2015, EN 61000-6-2:2019, EN 61000-6-4:2007+A1:2011, EN 62841-1:2015, EN 62841-2-2:2014 + AC:2015

EU SAR value0.54 W/kg

Tool familySTB

ETV STB64-40-10-BD

8433 3022 03
