Technical specifications

Dangerous goodsDG0

UN numbern/a

EU legislation2006/42/EC

Max working pressure6.3 bar

Max working pressure90 psig

Sound standardISO15744

Weight1.9 kg

Weight4.2 lb

Air consumption at max output72 cfm

Air consumption at max output34 l/s

Sound uncertainty3 dB(A)

Model typeAngle

Sound pressure77 dB(A)

Rec hose size5/8 in

Rec hose size16 mm

Air consumption at free speed19 cfm

Lubrication FreeYes

Vibration standardISO28927-3

Air inlet thread BSP3/8 in

Height4.1 in

Spindle length0.9 in

Support handle includedYes

Spindle thread5/8-11 UNC

Max free speed6000 r/min

Height105 mm

Auto balancerYes

Vibration uncertainty1.1 m/s²

Air consumption at free speed9 l/s

Vibration value3.8 m/s²

Height over spindle84 mm

Height over spindle3.3 in

Model typeAngle

Motor typeTurbine

Max output2.5 kW

Max output3.3 hp

EC standardEN ISO 11148-8

Spindle length23.4 mm

Max pad dia9 in

Max pad dia230 mm

EAC certifiedYes

SCIP2400a025-eddf-44cf-8094-1309996d96dd

GTG 25 S060-700

8423 2525 22
